Sulfur Based Ammoniation Fertilizer Granulation Equipment

Sulfur Based Ammoniation Fertilizer Granulation Equipment

The annual production of this type of plant fertilizer equipment ranges from 50KT to 300KT.

Technical Information
By adopting sulfuric acid-ammonia pipe reactor granulation technology, we successfully developed sulfur based ammoniation fertilizer granulation equipment.
The following will further describe for you our sulfuric acid-ammonia pipe reactor granulation technology.

Sulfuric acid-ammonia pipe reactor is designed based on TVA's sulfuric acid-ammonia double-nozzle technology. That is, our sulfur based ammoniation fertilizer granulation equipment utilizes a tubular reactor to replace traditional acid-ammonia nozzle, and it now adopts a hanging pipe reactor in stead of original embedded double-nozzle. Thus, improved fertilizer equipment features higher flexibility, higher quality, and higher operational reliability. Meanwhile, the production cost of our sulfur based ammoniation fertilizer granulator is also reduced.

Working Principle and Advantages
The following will describe for you the working principle and advantages of our sulfur based ammoniation fertilizer granulation machine, when the fertilizer equipment is used to produce potassium sulfate compound fertilizers.
1. The reaction between potassium chloride and sulfuric acid produces potassium sulfate and hydrogen chloride gas. With temperature dropping, produced hydrogen chloride gas will combine with H2O and form into 31% hydrochloric acid.
2. Put potassium hydrogen sulfate and liquid ammonia into the pipe reactor, and then we will be able to obtain high temperature slurry after the reaction between them.
3. Produced high temperature slurry is injected into sulfur based ammoniation fertilizer granulation equipment. Thus, the slurry, raw materials and returning materials will be mixed together and then form into particles. The granulating rate reaches 80%.
4. Our compound fertilizer equipment is equipped with a high efficiency and energy saving hot blast stove. Specially designed fan can satisfy the different demands on hot air.
5. This fertilizer equipment is designed with rational cooling capacity. We can also provide special anti-blocking agent, thus avoiding the aggregating of potassium sulfate.
6. Our sulfur based ammoniation fertilizer granulation equipment adopts highly efficient Venturi dust collector, cyclone dust separator and horizontal spray tank to deal with the dust and exhaust gas at production site, complying with emission standard.
7. It utilizes DCS standby centralized control method to control the dosing and production process, which helps ensure production condition and product quality.

As a professional manufacturer and supplier of organic fertilizer production machine in China, we utilize advanced manufacturing equipment and technology to produce sulfur based ammoniation fertilizer granulation equipment, as well as urea granulation process equipment, etc.

Up to now, we have passed ISO9001:2008 and ISO9001: 2000 certifications. Our fertilizer equipment, ball mills, shearing machines and other products are well received in India, Saudi Arabia, Malaysia, Iran, Turkey and more, due to their reliable quality, long service life and low price.

If you want to get more information about our sulfur based ammoniation fertilizer granulation equipment, please contact us.
